FEATURES
SPECIFICATION
| DESCRIPTION | CKCP-2 | CKCP-3 | CKCP-4 |
| LENGTH(in mm) | 680 | 790 | 830 |
| WIDTH(in mm) | 840 | 990 | 1470 |
| HEIGHT(in mm) | 1060-1370(Adjustable) | ||
| TYNE(in mm) | 150 x 40 | ||
| TYNE TO TYNE DISTANCE(in mm) |
N.A. | 470-700 | 490-700 |
| NO. OF TYNE | 1 | 2 | 3 |
| 3 POINT LINKAGE | CAT-1/2(optional) | ||
| ACCESSORIES (OPTIONAL) | Crusher | ||
| CRUSHER | M.S.Flats | ||
| CRUSHER LENGTH(in mm) | N.A. | 1110 | 1620 |
| WEIGHT WITH CRUSHER (in Kgs. app) |
N.A. | 400 | 450 |
| WEIGHT WITHOUT CRUSHER (in Kgs. app) |
115 | 235 | 350 |
| POWER REQUIRED (in HP) | 35-50 | 60-75 | 75-90 |
