FEATURES
SPECIFICATIONS
| DESCRIPTION | CKSLTDN-7 | CKSLTDN-9 | CKSLTDN-11 | CKSLTDN-13 |
| FRAME | Channel 75x40 mm | |||
| SPRING | 9.5mm WD,50mm OD,27 Coils | |||
| TYNES | 21mm (Hammer Forged) | |||
| PAIRS | M.S.Flat 50x8mm | |||
| ANCHOR PIN | 25mm | |||
| NUTS | Nylock | |||
| FRAME BOLT | M 12x32mm | |||
| TYNE BOLT | 16x90mm | |||
| LINKAGE 3 POINT | M.S.FLAT 50x12mm | |||
| SHOVEL | 8mm | |||
| LENGTH (in mm) | 1550 | 2000 | 2457 | 2910 |
| WIDTH (in mm) | 712 | |||
| HEIGHT (in mm) | 533 | |||
| TILLER PIN | 28 mm | |||
| WEIGHT (in Kg's Approx) |
175 | 215 | 250 | 300 |
| TRACTOR POWER (in HP) |
30-40 | 40-45 | 50-55 | 60 & Above |
