FEATURES
SPECIFICATION
| DESCRIPTION | CKTR-3 | CKTR-4 | CKTR-5 |
| FRAME | M.S.Square Pipe | ||
| DRAWBAR Sq. | 50mm Solid Shaft | ||
| FURROW | 2 | 3 | 4 |
| TYNE | 36mm Profile Cut Single Piece | ||
| LENGTH(in mm) | 1300 | 1880 | 2460 |
| HEIGHT(in mm) | 1066 | ||
| BLADE | 8mm | ||
| MOULD BOARD | 8mm | ||
| BAR POINT | 31mm(High Carbon) | ||
| 3 POINT LINKAGE LEVER | M.S.Flat 65x16mm Flat | ||
| CONNECTING ROD | 31mm Solid Square | ||
| WIDTH OF CUT(in mm) | 610 | 910 | 1210 |
| DEPTH OF CUT(in mm) | 350 | ||
| WEIGHT(in Kgs approx) | 215 | 320 | 430 |
| POWER REQUIRED(in HP) | 45-60 | 60-75 | 75 & above |
