FEATURES
SPECIFICATION
| DESCRIPTION | CKDHH-18 | CKDHH-20 | CKDHH-22 | CKDHH-24 | CKDHH-28 | CKDHH-32 |
| FRAME(mm) | 132mm Sq. Pipe (Prefabricated) | |||||
| GANG BOLT/AXLE(mm) | 40(Solid Sq.Rod) | |||||
| NO. OF DISC | 18 | 20 | 22 | 24 | 28 | 32 |
| TYPE OF DISC | Boron Notched Disc in front Gang & Plain Disc in rear Gang | |||||
| DISC DIAMETER(in mm) | 610x4.5T(24inch) or 660x6T(26 inch) | |||||
| WIDTH OF CUT (in mm approx) |
2100 | 2300 | 2500 | 2700 | 3100 | 3500 |
| DISTANCE BETWEEN DISCS | 228mm | |||||
| TYRE SIZE | 10.0/75-15.3(8-16PR),13.0/55-16(14PR),400/60-15.5(18PR) | |||||
| BEARING HUBS | 6 | 8 | ||||
| WEIGHT(in Kg Approx) | 1540 | 1630 | 1760 | 1845 | 2015 | 2170 |
| TRACTOR POWER (IN HP) | 65-75 | 80-90 | 90-110 | 115-135 | 140-165 | 170-190 |
