FEATURES
SPECIFICATION
| DESCRIPTION | CK2WTT-3 TON | CK2WTT-5 TON | CK2WTT-9 TON |
| OUTER DIMENSION(LXBXH) | 8X6X2 Feet (2435x1828x610mm) |
10x6x2 Feet (3048x1828x610mm) |
12x6x2 Feet (3658x1828x610mm) |
| MAIN CHASIS(in mm) | 125x65 | 150x75 | 200x75 |
| FLOOR SHEET(in mm) | 4 | ||
| SIDE WALL SHEET(in mm) | 3(Corrugated) | ||
| TYRES | 7.50X16/9.00X16 | ||
| RING HITCH(in mm) | 50 Dia. | 65 Dia. | |
| HYDRAULIC CYLINDER CAPACITY | 10 TON | 15 TON | |
| AXLE(BRAKE OPTIONAL)(in mm) | 75 Square | 90 Square | |
| AXLE BEARING | 32214 inner and 32214 outer | 32017 inner and 32211 outer | |
| LEAF SPRING(OPTIONAL) | 36" | 42" | |
| WEIGHT(in Kgs. approx) | 1014 | 1180 | 1553 |
| TRACTOR POWER(in HP) | 30-50 | 50-70 | 70-90 |
