FEATURES
SPECIFICATION
| DESCRIPTION | CKLLHD-6 | CKLLHD-7 | CKLLHD-8 |
| FRAME | Draw Bar mounting with the help of MS Flat section 75x20mm,520mm Long | ||
| SIDE SUPPORT | Crescent shape,MS Flat,Max. width 100mm,Minmwidth 35mm | ||
| THICKNESS OF PLATE(in mm) | 10 | ||
| THICKNESS OF BLADE(in mm) | 10 | ||
| 3 POINT LINKAGE | CAT-1/2(Optional) | ||
| CENTRE SUPPORT | MS Angle 40x5mm | ||
| LINKAGE PIN | 28mm | ||
| WORKING WIDTH(in mm) | 1850 | 2150 | 2460 |
| WEIGHT(in Kgs. approx) | 175 | 185 | 200 |
| POWER REQUIRED(in HP) | 30-35 | 40-45 | 55-60 |
