FEATURES
SPECIFICATION
| DESCRIPTION | CKNTT-5T | CKNTT-9T | CKNTT-12T |
| OUTER DIMENSION(LXBXH) | 10x6x1.75 Feet (3048x1828x524mm) |
12x6x2 Feet (3658x1828x610mm) |
14x7x2 Feet (4270x1828x610mm) |
| MAIN CHASIS(in mm) | 150x75 | ||
| FLOOR SHEET(in mm) | 4 | ||
| SIDE WALL SHEET(in mm) | 2(Corrugated) | ||
| TYRES | 4 nos. of 7.5x16 | 2 nos. of 7.5x16, 2 nos. of 9.00x16 | |
| HITCH BEAM(in mm) | 75x40 | 100x50 | 100x50 |
| RING HITCH(in mm) | 50 Dia. | ||
| AXLE(in mm) | 75 Square(Front & Rear) | 75 Square (Front),90 Square(Rear) | |
| AXLE BEARING | 32214 inner and 32213 | ||
| WEIGHT(in Kgs. approx) | 1550 | 1720 | 2000 |
| TRACTOR POWER(in HP) | 50-70 | 70-90 | 90-110 |
